How to replace the air chamber on an LG washing machine

Is your LG washer’s wash cycle turning into a water park show? A cracked or damaged air chamber could be to blame, leading to unwanted water overflow. Fear not—our handy how-to video just below shows you step-by-step how to replace the air chamber and keep your laundry room dry!

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

The air chamber in an LG washer is responsible for controlling the water level inside the tub. However, over time, the air chamber can develop cracks or become damaged, leading to water overflows during the wash cycle.

Replacing the air chamber is a quick and relatively easy repair that you can do yourself, saving you time and money. Let’s get started!

You can find a replacement air chamber 3504ER3002A here. If you need other replacement parts for your LG washer, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.

Watch here: How To: LG/Kenmore Air Chamber 3504ER3002A

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

What does the air chamber do?

The air chamber in an LG washer helps regulate the water level inside the tub during the wash cycle. It works with the water level sensor to provide the correct amount of water to the washer for each load.

When you start a wash cycle, the water level sensor detects the water level inside the tub by measuring the air pressure in the air chamber. The air chamber acts as a buffer, trapping a pocket of air that changes in pressure as the water level rises or falls.

As the tub fills with water, the air pressure in the chamber increases. The water level sensor senses this change in pressure and signals the washer to stop filling once the correct water level is reached.

However, over time, the air chamber can develop cracks or become damaged, compromising its ability to maintain the desired air pressure. When the air chamber is cracked, it may fail to accurately transmit the pressure changes to the water level sensor. As a result, the washer may overfill with water, causing leaks or spills.

Tools needed

• Phillips screwdriver
• Pliers
• Liquid soap
• Towel

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before attempting any maintenance or replacement work. This keeps you safe by preventing any risk of injury from electric shock.
• Turn off the water supply at the outlet before beginning repairs to any appliance parts that hold water. Have towels ready for any residual water in the system when removing parts.
• Wear insulated work gloves to protect your hands from sharp metal parts, pinching hazards and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access the interior parts.
• Clear your workspace of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with bare wet hands. Make sure the work area is completely dry.
• Check your user manual to see if there are specific installation or safety instructions for your part or appliance.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause injury.
• Wear safety glasses when working with chemicals, dust or cleaning large debris to prevent injury.
• If the appliance has recently been used, give it plenty of time for any heating parts to cool down before working on it.

Replacement steps

REMOVAL

Step 1

1. Using a phillips screwdriver, remove the four screws securing the rear access panel.
2. Carefully flex the rear panel and release the top tabs to detach it.
3. Take out the bottom of the panel to fully remove it.

Step 2

1. Identify the air chamber connected to the tub and locate the air hose attached to it.
2. Gently pull the air hose off the air chamber.
3. Using a phillips screwdriver, remove the two screws securing the air chamber.
4. To prevent any water spillage, place a towel on the floor beneath the air chamber.
5. Push down on the hose and, using pliers, squeeze and move the hose clamp up the hose.
6. Remove the air chamber from its installation.

Step 3

1. Slide the hose clamp onto the hose.
2. Squeeze the clamp with pliers and position it on the air chamber.
3. Apply a small amount of soap on the end of the air chamber to facilitate the installation of the hose.
4. Pay attention to a small tab on the air chamber that aligns with the cutout in the hose.
5. Slide the air chamber into the hose, ensuring the tab fits into the cutout.
6. Using pliers, slide the clamp onto the hose to secure it in place.
7. Attach the air chamber to the tub by inserting and tightening a couple of screws using a Phillips screwdriver.
8. Reattach the air hose to the air chamber snugly.

Step 4

1. Remove the towel placed on the floor to catch any water.
2. Reattach the rear access panel by aligning the tabs and securing it with the four Phillips screws.
3. Plug the washer back in. Turn on the water supply to the washer.
4. Run a cycle to check for any problems.

Additional information

Thanks for reading! We hope this guide helped you replace the air chamber on your LG washer.
