How to replace the auger drive blade in a Frigidaire fridge

Steven E / Thursday April 4, 2024

The drive blade (also known as a drive plate) on the auger in a Frigidaire refrigerator connects the motor to the auger and allows it to turn and push ice through the dispenser. If the auger drive blade is stripped and spinning freely, then ice can’t be dispensed from the fridge.

You might need to change out this part if it failed testing or has been damaged.

If you need any replacement parts for your Frigidaire refrigerator, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Disclaimer: The part replacement information in this article is based on general service manuals and may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

Contents hide

I How to replace the auger drive blade in a Frigidaire fridge

I.I What you need

I.II Safety tips

I.III How to replace the auger drive blade

I.III.I Step 1: Access the auger motor

I.III.II Step 2: Remove the auger drive blade

I.III.III Step 3: Install the new auger drive blade

I.III.IV Final steps

I.IV FAQs

I.IV.I Q: How can I extend the life of my refrigerator after a repair?

I.IV.II Q: How do I clean the condenser coils on my refrigerator, and how often should I do it?

I.IV.III Q: What temperature should my refrigerator be?

I.V More information

I.V.I Share this entry

What you need

Phillips head screwdriver
1/4-inch nut driver

Disclaimer: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Safety tips

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by preventing any risk of electric shock.
Turn off the water supply at the outlet before beginning repairs. Keep towels ready to catch any residual water in the system when removing parts.
If the appliance has recently been used, give it plenty of time to cool down before working on it.
Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
Work in a well-lit area so you can clearly see and access appliance parts.
Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
Never work on internal parts with wet hands. Make sure the work area is completely dry.
Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
Wear insulated work gloves to protect your hands from sharp metal parts and debris.
When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
Consider wearing safety glasses and/or a dust mask when working with chemicals, dust or a large amount of debris to prevent irritation or injury.

How to replace the auger drive blade

Step 1: Access the auger motor

Turn off the fridge and unplug it from the power source.
Disconnect the water supply from the fridge.
Open the freezer door and slide the ice bin out.
At the bottom of the auger housing, find the 2 – 1/4-inch screws and remove them.

Step 2: Remove the auger drive blade

Lift the auger housing up and off the rails.
Set the auger housing on a table with a towel.
Disconnect the wiring to the auger motor.
Remove the auger drive blade by using a mallet to tap the auger blade until it knocks off.

Step 3: Install the new auger drive blade

Screw the new auger drive blade back in place and tap it with the mallet until it’s tight.
Reconnect the wiring to the auger motor.
Hang the auger housing back on the rails.
Reinstall the 2 – 1/4-inch screws.
Slide the ice bin back into place and close the freezer door.

Final steps

Plug your fridge back in or flip the circuit breaker back on.
Reconnect the water supply to the fridge.
Give the fridge a few hours to make ice, then test it to see if it dispenses ice.

FAQs

Q: How can I extend the life of my refrigerator after a repair?

A: Regular maintenance can extend the life of your refrigerator and help you get the most out of replacement parts. This includes cleaning the coils, checking the door seals, and keeping the fridge and freezer at the recommended temperature. Addressing any issues promptly can also prevent more significant problems down the road.

Q: How do I clean the condenser coils on my refrigerator, and how often should I do it?

A: Unplug the refrigerator, find the condenser coils (which are usually at the back or beneath the fridge), and use a coil brush or vacuum to remove all dust and debris. You should clean the coils at least once a year so your refrigerator stays in good working condition.

Q: What temperature should my refrigerator be?

A: The recommended temperature for a refrigerator is between 35 and 38 degrees Fahrenheit (1 to 3 degrees Celsius). This range keeps perishable foods fresh and prevents bacterial growth. For a freezer, the ideal temperature is around 0 degrees Fahrenheit (-18 degrees Celsius).
