How to replace the cycling thermostat in a Speed Queen dryer

If your Speed Queen dryer isn’t reaching the right temperature, cycles on and off or shuts off prematurely during a cycle, then it may have a faulty cycling thermostat. The cycling thermostat monitors and regulates the interior temperature so your dryer can maintain the set temperature.

Over time, the cycling thermostat can become damaged or worn out from regular use. But with a few tools, this guide, a new part and a bit of patience, you can swap out the cycling thermostat and get your dryer running smoothly again.

If you need any replacement parts for your Speed Queen dryer, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Important: The part replacement information provided in this article is based on model ADE4BRGS171TW01 and may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What you need

• Replacement cycling thermostat (make sure it’s compatible with your specific dryer model before installing)
• 1/4-inch nut driver

Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more:  Dryer Making Noise? How to Fix & Troubleshooting

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.

Read more: DIY Dryer Troubleshooting: What Is Causing Slow Drying Times?

How to replace the cycling thermostat

Follow these steps to change out the cycling thermostat in your Speed Queen dryer.

Step 1: Access the thermostat

1. Unplug the dryer from the electrical outlet.
2. Use a 1/4-inch nut driver to remove the two screws at the bottom of the front access panel.

Step 2: Install the new thermostat

1. Remove the 1/4-inch screws that hold the old cycling thermostat to the blower housing.
2. Install the new cycling thermostat with the 1/4-inch screws.
3. Switch the wires from the old thermostat over to the new one.

Step 3: Reassemble the dryer

1. Rotate the bottom panel back into place and secure it with the 1/4-inch screws.
2. Plug the dryer back in.
3. Test the dryer to make sure the new cycling thermostat is working correctly.

Read more: Troubleshooting Tips for a Dryer Drum That Does Not Turn

More for you

Thanks for reading! We hope this guide helped you replace the cycling thermostat in your Speed Queen dryer.
