How to replace the water valve assembly 5221JB2006K on an LG refrigerator

Is your LG refrigerator’s water dispenser on the fritz or the ice maker leaving you high and dry? If so, a faulty water valve assembly might be the culprit! Dive into this easy DIY guide to tackle the issue head-on and follow along with a how-to video just below to get your appliance back in tip-top shape.

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

On an LG refrigerator, the water valve assembly 5221JB2006K is responsible for controlling the flow of water to the dispenser and ice maker, allowing your refrigerator to provide water and ice. Common signs that indicate the need for replacement include no water being dispensed, water dripping from the dispenser, a frozen inlet tube, or a visibly cracked valve. Fortunately, with a few basic tools and some patience, you can tackle this repair yourself and get your refrigerator back in working order. So, let’s get started!

If you need any replacement parts for your appliance, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

Watch here: How To Replace: LG/Kenmore Refrigerator Water Inlet Valve Assembly 5221JB2006K

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before attempting any maintenance or replacement work. This keeps you safe by preventing any risk of injury from electric shock.
• Wear insulated work gloves to protect your hands from sharp metal parts, pinching hazards and debris.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access the interior parts.
• Clear your workspace of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with bare wet hands. Make sure the work area is completely dry.
• Check your user manual to see if there are specific installation or safety instructions for your part or appliance.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause injury.
• Wear safety glasses when working with chemicals, dust or cleaning large debris to prevent injury.
• If the appliance has recently been used, give it plenty of time for any heating parts to cool down before working on it.
• Take pictures or make a note of wiring terminals or other connections before disconnecting to prevent any problems with reassembly.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.

Tools and materials needed

• Replacement part (make sure it’s compatible with your model before installing)
• 1/2″ wrench
• Phillips screwdriver
• Flathead screwdriver
• Side-cutters

Replacement steps

Step 1: Disassembly and removal

1. Open the doors to access the bottom grill.
2. Remove the bottom grill by unscrewing the two Phillips screws using a Phillips screwdriver. Slide the grill off.
3. Place a towel on the floor under the joint to catch any potential water drips.
4. Remove the locking rings on each side of the coupling by pushing them off.
5. Push in the locking collar and pull out the first tube, then proceed with the second tube.
6. Remove the towel after the water has drained.
7. Move to the back of the fridge to access the rear panel.
8. Remove the water inlet hose using a half-inch open-end wrench. Make sure the water is turned off at the faucet as some water may drip out.
9. Unscrew the rear access panel using a Phillips screwdriver, then pull the panel up to disengage the tabs at the bottom.
10. Remove the water inlet valve by unscrewing the single Phillips screw and pulling it out. Place a towel underneath for any remaining water.
11. Disconnect the water lines by removing the safety clip and pressing the locking collar to pull out the lines.
12. Remove any remaining water lines by pressing on the locking collar and pulling them out.
13. Take a picture of the plugs to remember their positions before removing them.
14. Remove the plugs using a flathead screwdriver.
15. Cut the zip tie to free the harness and complete the disassembly.

Step 2: Installation and reassembly

1. Install the new water inlet valve by inserting the locking clips in place.
2. Connect the water lines to the new valve.
3. The large 5/16″ line connects to the main water supply.
4. The smaller line connects to the water filter.
5. Push both lines in fully.
6. Reconnect the harness wires by plugging them into their respective terminals.
7. Connect the water tubes.
8. The larger 5/16″ tube connects to the white coupling.
9. The smaller quarter-inch tube connects to the blue/orange coupling.
10. Press them in securely.
11. Install the new valve assembly by securing it in place with a Phillips screw.
12. Pull the tube forward from the front of the fridge to eliminate slack in the back.
13. Install the locking collars on the couplings.
14. The small collar goes on the small vent.
15. The large collar goes on the large vent.
16. Insert the tubes fully.
17. Reinstall the grill by sliding it into place and securing it with two Phillips screws.
18. Install the valve by bending the mounting bracket if necessary to match the holes, then secure it with a Phillips screw.
19. Reattach the rear access panel by aligning the brackets with the pins and securing it with Phillips screws.
20. Reconnect the water line by manually threading it and tightening it with a half-inch open-end wrench (do not overtighten).
21. Remove the towel, plug the fridge back in, turn on the water supply, and check for any leaks.

Additional information

Thanks for reading! We hope this guide helped you replace the water valve assembly on your LG refrigerator.
