How to replace Whirlpool washer door seal WPW10237499

Is your Whirlpool washer leaking water? A worn-out door seal (also known as a gasket) is likely the culprit.

Replacing the door seal is an easy do-it-yourself repair that you can tackle in less than an hour.

If you still need a replacement door seal, you can find it here. Looking for more Whirlpool washer parts? Just enter your model number at AppliancePartsPros.com to find them. We’ve got thousands of free guides to help you fix your appliances yourself.

Ready? Let’s walk through the entire door seal replacement process.

Watch the full repair here

Disclaimer: The part replacement information provided in this article is based on general service manuals and may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What does the door seal do?

The flexible door gasket/seal is usually made of rubber and creates a tight seal between the outer tub and the front door panel of your washing machine. Over time, repetitive opening and closing of the door can cause the gasket to develop cracks or holes, which can allow water to leak out during the wash cycle. It’s important to replace a damaged door gasket as soon as possible to stop the leaking and prevent potential water damage to your floors.

Read more: 5 Ways To Keep Your Clothes Washer In Great Shape

What you need

• 1/4-inch nut driver
• 5/16 inch nut driver
• Torx 20 screwdriver
• Socket wrench with 1/2 inch head
• Flat blade screwdriver
• Phillips screwdriver
• Locking pliers
• Wooden block
• Replacement door seal WPW10237499 (make sure it’s compatible with your washer model)

Replacement instructions

Step 1: Remove the washer top

1. Use a quarter-inch nut driver to remove the three back screws.
2. Push the top back slightly and lift off.

Step 2: Detach the control panel

1. Remove the detergent dispenser drawer.
2. Remove two Torx 20 screws beneath the drawer opening.
3. Release the locking tabs and unplug the control panel wiring.

Step 3: Remove the door components

1. Take off the screw above the door latch and remove the latch.
2. Use a flat-blade screwdriver to pry off the retaining spring around the door seal opening.
3. Pull back the inner lip of the door seal.

Step 4: Tilt the washer back

1. Close the door and carefully tilt the washer back on its rear feet.
2. Place a wooden block under the front bottom edge to support the washer.

Step 5: Remove the front panel

1. Remove the four screws at the bottom of the front panel.
2. Tilt the washer slightly, remove the support block, and take off the panel.

Read more: Washing Machine is Leaking: Top 6 Reasons and Fixes

Step 6: Remove the old door seal

1. Detach the inlet fill tube from the outer tub.
2. Pull out the light bulb housing from the tub opening.
3. Use a 1/2-inch socket wrench to remove three bolts and the concrete counterweight block.
4. Use a Phillips screwdriver to unscrew the seal clamp at the top of the tub.
5. Slide clamp off the top and sides of the seal.
6. Grasp the old seal and pull it off the tub.

Step 7: Install the new door seal

1. Make sure the new seal is uncoiled and pliable. If needed, soak it in some warm water and dry it off so you can apply it easier.
2. Press the outer lip of the seal onto the top of the tub opening.
3. Press the seal into place as you work your way around the tub. Attach the inner lip last.
4. Slide the metal clamps back over the new seal at the top of the tub.
5. Tighten the clamp screw.
6. Bolt the counterweight concrete block back into place.
7. Reconnect the inlet tube and replace the light bulb housing.

Read more: Surprising Things That Can & Can’t Go in the Washer

Step 8 – Reassemble the washer

1. Set the front panel back into place and secure it with screws along the bottom edge.
2. Replace the door latch assembly.
3. Press the outer door seal lip back into place.
4. Install the retaining spring around the seal opening.
5. Reconnect the control panel wiring and reattach the panel.
6. Replace the detergent dispenser.
7. Set the top back on the washer and tighten the screws.

Final steps

1. Turn the water supply back on.
2. Plug the washer power cord into the outlet.
3. Turn on the washer and run a small test cycle to check for leaks.
