How to Test and Replace the Door Boot Seal on an LG Washer

Is your LG front-load washer leaking or leaving puddles on the floor? A worn or damaged door boot seal is likely the culprit. Over time, this rubber gasket can tear or develop mold, causing water to escape. We’ve got expert tips to help you test and replace the seal for a leak-free wash!

If you need any replacement parts for your LG front load washer, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

What you need

• Phillips screwdriver
• Adjustable pliers
• Flat blade screwdriver
• Side cutter
• Zip tie
• Door boot seal clamp removal tool (p/n 383EER4000A)

Safety tips

Your safety should always be the top priority when performing any appliance repair.

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.
• Consider wearing safety glasses and/or a dust mask when working with chemicals, dust or a large amount of debris to prevent irritation or injury.
• Turn off the water supply at the outlet before beginning repairs. Keep towels ready to catch any residual water in the system when removing parts.

How to test and replace the LG washer’s door boot seal

Here are the steps to remove the old door boot seal, install a new one, and reassemble your LG washer for proper operation.

Step 1: Access the door boot seal

Unplug the washer from the power source. Turn off the water supply to prevent leaks.

1. Open the filter door at the bottom left of the washer.
2. Pull the drain hose out of the clip.
3. Use a Phillips screwdriver to remove the two screws securing the filter housing.
4. Pull out the white filter housing from the washer.
5. Remove one more Phillips screw at the bottom of the housing.
6. Move to the back of the washer.
7. Use a Phillips screwdriver to remove the two bottom screws from the plastic brackets, one on each side.
8. Slide the top panel back slightly and lift it off.
9. Go to the front of the washer.
10. Pull the detergent dispenser out and press the locking tab to remove it.
11. Remove two Phillips screws from the sides of the dispenser opening.
12. Locate and remove one more Phillips screw inside the right-side corner of the panel.
13. Pull the top edge of the control panel forward to release the clips.
14. Open the two retainer ties and disconnect the plug connectors.
15. Lift and remove the control panel completely.
16. Open the washer door.
17. Use a flat-blade screwdriver to pry out the retainer spring holding the boot seal.
18. Pull the door seal off the outer lip and push it inside.
19. Remove two Phillips screws securing the door latch and push it inside the washer.
20. Move to the top of the front panel.
21. Remove six Phillips screws securing the front panel.
22. Tilt the front panel outward and lift it off the bottom hinges.

Step 2: Remove the old door boot seal

1. Remove the right-side hose by removing the Phillips screw from the clip, squeezing the clamp, and pulling the hose off.
2. Remove the left-side hose using the same procedure.
3. Remove the bottom drain hose by squeezing the clamp and removing the coupling.
4. Remove the top black hose by moving the clamp up with pliers and pulling the hose out.
5. Cut the zip tie securing the light assembly and remove the light.
6. Use a clamp removal tool to stretch the spring retainer clamp and slide it off.
7. Remove the old boot seal from the washer’s tub lip.

Step 3: Install the new door boot seal

1. Push out the dual hose adapter from the old boot seal.
2. Apply a small amount of dish soap to the adapter and install it onto the new seal.
3. Apply a thin layer of liquid soap inside the groove of the new seal.
4. Install the new door boot seal onto the tub lip.
5. Check that the seal is fitted correctly.
6. Install the inner retainer ring into the groove.
7. Use a boot seal clamp tool to stretch the spring retainer clamp and secure it onto the hook.
8. Confirm that the retainer clamp is installed properly.
9. Pull on the seal to make sure it is secure.
10. Reconnect the black hoses on both sides and secure them with clamps.
11. Secure the plastic retainers with Phillips screws.
12. Reconnect the bottom drain hose and secure it with a clamp.
13. Reconnect and clamp the top black hose.
14. Apply soap to the left-side tube and reinstall the end cap using pliers.
15. Install the light assembly and secure it with a new zip tie.
16. Trim any excess zip tie with side cutters.

Step 4: Reassemble the washer

1. Place the front panel onto the bottom hinges.
2. Tilt the panel forward and lock the right side into place under the clip.
3. Use a Phillips screwdriver to secure the panel with six screws.
4. Reach in and pull out the door latch assembly.
5. Secure the door latch with two Phillips screws.
6. Pull the door boot seal over the outer lip, making sure it is properly positioned.
7. Apply dish soap to the retainer spring for easier installation.
8. Position the retainer spring ring inside the groove with the spring at the 6 o’clock position.
9. Use a boot seal clamp tool to stretch the retainer spring and install it into the groove around the seal.
10. Check that the spring is evenly positioned inside the groove.
11. Pull firmly on the seal to make sure it is secure.

Step 5: Reinstall the control panel

1. Bring the control panel back into place.
2. Pull the wiring harness through and reconnect all plug connectors.
3. Secure the wiring with two retainer ties.
4. Clip the control panel onto the washer by pushing it forward.
5. Secure it with one Phillips screw in the right corner.
6. Install two Phillips screws on both sides of the detergent dispenser opening.
7. Clean the detergent drawer and slide it back into place.

Step 6: Reinstall the top panel

1. Align the top panel and push it forward to lock it into place.
2. Secure it with two Phillips screws at the back.
3. Confirm that the drain hose is inside the standpipe and secured.
4. Turn the water supply back on and check for any leaks.
5. Plug the washer back into the electrical outlet.
6. Run a test cycle to check that the washer is operating properly.
7. Look for leaks, door seal fit, and correct function.
