How to test & replace a door switch on a Kenmore electric dryer: A guide from the experts

Fixing your Kenmore electric dryer doesn’t have to be a headache. Learn how to test and replace the door switch with our expert tips and skip the repair call!

If you need any replacement parts for your Kenmore dryer, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Important: The troubleshooting information in this article is based on model 11068722700 and may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What you need

• Putty Knife
• 1/4 inch nut driver
• Phillips head screwdriver
• Multimeter

Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Safety precautions

When working on any appliance, always keep safety first to avoid personal injury or damage to the appliance or its parts. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.
• Don’t test live voltage with a multimeter if you’re unfamiliar with how to prevent short-circuiting.
• Consider wearing safety glasses and/or a dust mask when working with chemicals, dust or a large amount of debris to prevent irritation or injury.

Read more: Tips for Caring for Your Dryer | Clothes Dryer Maintenance

How to test and replace the door switch on a Kenmore electric dryer

Step 1. Access the door switch

1. Use a putty knife to press the two clips that secure the control console.
2. Push the control console upward and back to remove it.
3. Remove the three ¼-inch screws holding the top panel of the dryer.
4. Lift off the top panel to expose the door switch on the right side.
5. Disconnect the door switch by separating it from the connector.

Step 2. Test the door switch

6. Set your multimeter to continuity mode.
7. Check the two pins connected to the door switch.
8. Ensure there is continuity when the door is closed. If there is no continuity, the switch is faulty and needs replacement.
9. Inspect the door tab to see if it’s broken or missing.

Step 3. Remove the faulty switch

10. Reconnect the switch to the connector for stability.
11. Use a Phillips head screwdriver to remove the two screws holding the door switch.
12. Carefully disconnect the door switch from the connector after unscrewing.

Step 4. Install the new door switch

13. Plug the new switch into the connector.
14. Position the new switch in place and secure it with the two screws.
15. Replace the top panel of the dryer and secure it with the three screws.
16. Clip the control console back into place.
17. Reconnect the dryer by plugging it in or turning the circuit breaker back on.

Read more: How To Replace A Dryer Door Switch

Looking for more?

Thanks for reading! We hope this guide helped you test and replace the door switch in your Kenmore dryer.
