How to test & replace an electric Samsung range broil element

If your Samsung electric range’s broil function isn’t working properly, the broil element might be the issue. The broil element is responsible for generating the heat needed for broiling, and if it’s faulty, your oven won’t reach the correct temperatures. We’ll walk you through how to test the broil element to determine if it’s faulty and, if needed, how to replace it, so you can get your oven back to working as it should.

If you find out that you need any replacement parts for your appliance while you’re troubleshooting, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Important: The error code information provided in this article may not apply to your specific appliance model. The disassembly information is based on models starting with FTQ387LWGX. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before attempting any maintenance or replacement work. This keeps you safe by preventing any risk of injury from electric shock.
• Wear insulated work gloves to protect your hands from sharp metal parts, pinching hazards and debris.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access the interior parts.
• Clear your workspace of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with bare wet hands. Make sure the work area is completely dry.
• Check your user manual to see if there are specific installation or safety instructions for your part or appliance.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause injury.
• Wear safety glasses when working with chemicals, dust or cleaning large debris to prevent injury.
• If the appliance has recently been used, give it plenty of time for any heating parts to cool down before working on it.
• Take pictures or make a note of wiring terminals or other connections before disconnecting to prevent any problems with reassembly.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.

Read more: Oven Door Won’t Close: 4 Reasons & Fixes

Tools and materials needed

• Phillips head screwdriver

Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more: How to Replace an Oven Bake Element

Troubleshooting steps

Step 1: Access the broil element

1. Unplug the range or turn off the breaker to disconnect it from the power supply.
2. Slide the range out from the wall to access the back.
3. Use a screwdriver to remove the rear lower cover on the back of the range, which will expose the broil element connections.

Step 2: Test the broil element

LIVE VOLTAGE WARNING: For this test, the appliance needs to be plugged in and powered on. Please be very careful to protect yourself from electric shock, which has the potential to cause serious injuries. Don’t ever test live voltage if you’re uncomfortable using a multimeter.

1. Locate the broil element at the upper section of the oven, on the back.
2. Set the oven to broil mode and plug the range back in.
3. Set your multimeter to VAC (volts AC).
4. Place the multimeter probes on each terminal of the broil element.
5. You should get 240 VAC on the multimeter.

If you get 240 VAC but the element doesn’t heat up, the broil element is faulty and needs replacement. If you don’t get 240 VAC, the issue may be with another component, such as the control board.

Step 3: Replace the broil element

1. Unplug the range again or turn off the breaker before removing the element.
2. Disconnect the wires from the broil element at the back of the range.
3. Open the oven door and locate the screws securing the broil element to the rear wall and ceiling of the oven.
4. Use a screwdriver to remove these screws.
5. Gently slide the broil element out of the oven.
6. Slide the new broil element into the same position inside the oven.
7. Reinstall the screws to secure the element to the rear wall and ceiling.
8. Reconnect the wiring to the broil element at the back of the range.
9. Reattach the rear lower panel of the range.
10. Plug the range back in or turn the breaker back on.
11. Test the oven by setting it to broil and ensure the new element is heating properly.
