Troubleshooting GE refrigerator error code F6

Is your GE refrigerator displaying error code F6? Don’t worry, this is a problem that you can troubleshoot and fix yourself without the need for a costly service call. We’re here to help you do it!

If you find out that you need any replacement parts for your appliance while you’re troubleshooting, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Important: The error code information provided in this article may not apply to your specific appliance model. The disassembly information is based on GE models Adora, Cafe, and Profile french door refrigerators from 2014-2015. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What the error code means

Error code F5 indicates a problem with the fresh food section evaporator thermistor which is responsible for monitoring the temperature of the refrigerator section evaporator and providing that information to the refrigerator’s control board to determine when to defrost the evaporator coils. When the control board detects an invalid or out-of-range reading from the thermistor, it will trigger the error code.

Read more: Causes of condensation around a refrigerator’s French doors

Tools and materials needed

• 1/4”, 5/16” and 3/8” Nut drivers, sockets or wrenches
• T15, T20 and T27Torx bits
• Flathead screwdriver
• Phillips screwdriver
• Wire strippers
• Multimeter
• Silicone grease
• Bell connectors

Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more: Refrigerator error codes: What do they mean & how can I fix them?

Troubleshooting steps

Access the thermistor

1. Disconnect power to the refrigerator.
2. Remove the shelves from the refrigerator fresh food section including the deli pan slides.
3. The deli pan slides can be access by removing the two 1/4 in. hex head screws from
4. the top of the deli pan covers.
5. Lift the front deli pan cover and disconnect the wire harness.
6. Remove the recessed 1/4 in. hex head screw that attaches the front of the slide support to the liner wall.
7. Pull the slide support toward the front of the refrigerator to remove it.
8. Press down and remove the fan harness cover on the rear wall.
9. Remove the five ¼ inch hex head screws attaching the evaporator cover to the back wall of the refrigerator section at the top of the cover.
10. Tilt the top of the evaporator cover out and disconnect the deli pan fan and damper wire harness.
11. Remove the cover.
12. The thermistor is attached to the evaporator inlet tube on the right side with a metal clip.

Test the thermistor

1. Remove the thermistor and place it in a glass of ice water (approximately 33°F) for several minutes.
2. Using a multimeter, check the resistance of the thermistor. It should read approximately 16k ohms when in the ice water.
3. After testing in the ice water, check the resistance at room temperature. It should read approximately 6k ohms.
4. If the thermistor does not read the expected resistance values, it is faulty and needs to be replaced.
5. If the thermistor tests within the normal range at both temperatures and the error code continues, replace the main control board.

Replacement steps

1. Place the replacement thermistor next to the original thermistor.
2. Cut the wiring at a location that will match the original length when the replacement thermistor is spliced to it.
3. Use plastic bell connectors. Fill each connector with silicone grease, then splice the new thermistor into the harness.
4. Slide the thermistor back into the metal clip on the evaporator.
5. Reinstall the vegetable bins, vegetable bins cover, and deli pan.
6. Plug the refrigerator back into the outlet.

Read more: Why Is My Refrigerator Not Cooling?

Additional information
