How to replace an LG or Kenmore freezer drawer rail assembly

Struggling to slide your LG or Kenmore refrigerator’s freezer drawer? A jammed freezer is a hassle no homeowner wants, but the good news is that swapping out the rail assembly is simpler than you might think! Dive into our step-by-step guide below, complete with a how-to video that makes this DIY repair a breeze.

Is your LG or Kenmore refrigerator’s freezer drawer not sliding in and out smoothly? Replacing the freezer drawer rail assembly only takes a few minutes and can help get things moving freely again.

Watch the full repair here.

Safety tips

Any time you’re tackling repairs on an appliance, disconnect the power to avoid any risk of electric shock. For refrigerators, the best practice is to unplug the unit from the wall outlet or shut off the circuit breaker that supplies power to the refrigerator.

Necessary parts and tools

To replace the freezer drawer rail assembly, you’ll need to purchase the new slide rail assembly designed specifically for your model. The part number for most LG and Kenmore models is AEC73337401 and can be purchased by clicking here.

Double-check that you’re ordering the correct part for your make and model to get the right fit and operation.

In addition to the new slide assembly, you’ll also need a Philips head screwdriver and a flat-head screwdriver

Remove the old assembly

Replacing the freezer drawer rail is a sequential process. Here’s how to remove the existing faulty assembly:

1. Open both French doors on the refrigerator to access the freezer drawer area. Having full access is key for easy removal.
2. Open the freezer drawer as wide as it will extend. Pulling the drawer out provides the clearance needed to detach the rails.
3. Use a flat-head screwdriver to lift up the locking tab on each side of the drawer. Lift up on the drawer sides while pushing back to release the drawer from the rails. Set the drawer aside.
4. Take out the removable freezer basket and tray. This fully clears the workspace to uninstall the old slide assembly.
5. Use a Philips head screwdriver to remove the screw on each side securing the rail assembly. With both screws out, the assembly can be detached.
6. Carefully maneuver the old slide assembly to unhook it from the refrigerator wall and remove it. Now you’re ready to install the new replacement part.

Install the new rail assembly

Installing the new freezer drawer rail assembly is done by reversing the removal steps. How to mount the new part:

1. Line up the new slide assembly into position, aligning the holes. Press the assembly flush to the refrigerator wall.
2. Insert and tighten the Philips head screws on each side to secure the assembly in place.
3. Pull out the slide rails, then rehang the freezer door. Hook the back first, then press down on the front to lock the door in place.
4. Replace the two Philips head screws on the sides of the door to fully secure it.
5. Slide the freezer basket and tray back into their mounted positions on the new rails. Make sure they glide smoothly.
6. Extend the slide rails fully, then insert the freezer drawer. The locking tabs will click into place on the back and front.

Complete the repair

You’re in the home stretch once the new freezer drawer rail assembly is installed. Finish up with these last steps:

1. Confirm the freezer basket is placed wherever desired inside the drawer for storage.
2. Close the freezer door and ensure it seals properly without any gaps.
3. Plug the refrigerator power cord back in or turn on the circuit breaker.
4. Allow the fridge to cool back down.
5. Verify the freezer is functioning normally.

More information

Thanks for reading! We hope this article helped you replace the drawer rail assembly in your LG or Kenmore refrigerator.

If you have any other questions or need some extra assistance, feel free to contact us at 1 (877) 477-7278 and one of our pros will be happy to help. Don’t hesitate to explore our other resources and guides available at AppliancePartsPros.com for all your other appliance repair needs and projects. In addition to selling over two million original equipment manufacturer parts, we offer free tech support on our website and thousands of free tutorials on our YouTube channel.
