How to replace KitchenAid stand mixer transmission housing 8212396

Is your KitchenAid stand mixer leaking grease or making odd noises? It might be time to replace the transmission housing, and the best part is—you can do it yourself in just a few simple steps! Watch our how-to video below and follow our guide to keep your trusty kitchen companion running smoothly.

Need a part?  Search below using your appliance model number to find exactly what you need:

The transmission housing covers the gears inside a KitchenAid stand mixer. Over time, the housing may become cracked or damaged, which can lead to grease leaks.

But we’ve got good news for you: you can replace the transmission housing yourself in just a few minutes! Check out the following instructions so you can save money and get your KitchenAid stand mixer up and running smoothly again in no time.

If you need a replacement transmission housing for your KitchenAid stand mixer, you can use your model number to find what you’re looking for at AppliancePartsPros.com. We also have thousands of free DIY troubleshooting and repair guides to help you fix your mixer yourself.

Watch here: How To: Whirlpool/KitchenAid/Maytag Transmission Housing 8212396

What you’ll need

• Phillips screwdriver
• Small flathead screwdriver
• Razor blade
• Drill with 11/32-inch bit
• New transmission housing (make sure it’s compatible with your specific model before installing)

Disclaimer: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more: How To Clean And Maintain Your Stand Mixer

Check part compatibility

Before you replace the transmission housing, make sure you have an OEM part that’s compatible with your specific stand mixer model. To do this, you’ll need to find the appliance model number.

The model number will say MOD or Model before the numbers and is typically found on a sticker or a metal plate in one of the following locations:

• On the underside of the mixer’s base
• On the back of the mixer’s head or motor housing
• On the side of the mixer’s base

Once you’ve found the model number, write it down or take a clear photo of it for reference.

Next, visit AppliancePartsPros.com, where you can enter your model number to check if the transmission housing 8212396 is compatible with your model.

Read more: KitchenAid Stand Mixer Attachments To Try

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by preventing any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can clearly see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.

How to replace the transmission housing in your mixer

Follow these steps to switch out the transmission housing in your KitchenAid stand mixer.

Step 1: Remove the old transmission housing

1. Unplug the mixer from the outlet.
2. Put the mixer bowl in the down position.
3. Lift the beater, turn it clockwise, and let it drop down so you can remove it.
4. Lift the bowl off the mounting pegs and pull it out.
5. Use a Phillips screwdriver to remove the screw that holds the trim on the back of the mixer.
6. Pull the trim off and set it aside.
7. Use a Phillips screwdriver to remove the four screws (two on each side) that hold the cover on.
8. Lift the cover off and set it aside.
9. Use a Phillips screwdriver to remove the two screws that hold the speed control board in place.
10. Lift the control board and move it out of the way.
11. Use a small flat-head screwdriver to press on each side of the tabs that hold the sensor in place.
12. Pull the sensor out of the motor.
13. Swing the speed control board out of the way.
14. Use a Phillips screwdriver to remove the four screws that are holding down the transmission housing.
15. Carefully lift the transmission housing off.
16. Pull out the hub attachment gear by pushing it into the housing and lifting it out.

Step 2: Install the new transmission housing

1. If the bearing is stuck on the shaft, carefully remove it.
2. Clean the area around the transmission housing to remove any grease.
3. Set the hub attachment gear into the new transmission housing.
4. Align the housing and turn it over to set it down into place. If the original housing locator pins broke inside the base, you’ll need to carefully remove them or drill them out.
5. Turn the hub gear slightly to align the teeth. Make sure the housing goes down completely.
6. Use a Phillips screwdriver to secure the screws on the transmission housing.
7. Lift the speed control so you can put it back in position.
8. Use a Phillips screwdriver to secure the screws on the speed control board.
9. Plug the sensor back into the motor by aligning it and pushing it down until it locks in place.
10. Set the top cover into place and use a Phillips screwdriver to reinstall its screws.
11. Place the trim ring on the back and use a Phillips screwdriver to secure it.
12. Line up the pins on each side of the mixer and place the bowl back on.
13. Push down on the back of the bowl to snap it into place.
14. Line up the beater on the shaft. Make sure the pin goes into the cutout, then lift it into place.
15. Turn the beater counterclockwise to lock it into place.
16. Plug the mixer back in.
17. Test the mixer to check for any problems.

Read more: How To Clean And Maintain Your Stand Mixer

Additional information

Thanks for reading! We hope this guide helped you replace the transmission housing on your KitchenAid stand mixer.
