How to replace the suspension spring on an LG washer

Tired of the thumping noise or shaky tub during your LG washing machine’s spin cycle? It’s likely a suspension spring issue, and we’ve got the perfect DIY solution for you! Dive into our step-by-step guide below and watch the accompanying video to confidently replace the suspension spring yourself.

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

On an LG washer, the suspension springs attach to the top of the cabinet and to the side of the outer tub. These springs help to stabilize the tub and prevent unbalanced or vibrating during the spin cycle. Luckily, replacing this part is a relatively quick and straightforward repair that you can easily do yourself.

Watch here: How To: LG/Kenmore Suspension Spring 4970FR2084P

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

Tools needed

• Phillips screwdriver
• Flathead screwdriver
• Rope

Safety precautions

• Always power off and unplug your appliance or switch off the circuit breaker before attempting any maintenance or replacement work. This keeps you safe by preventing any risk of injury from electric shock.
• Turn off the water supply at the outlet before beginning repairs to any appliance parts that hold water. Have towels ready for any residual water in the system when removing parts.
• Wear insulated work gloves to protect your hands from sharp metal parts, pinching hazards and debris.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access the interior parts.
• Clear your workspace of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with bare wet hands. Make sure the work area is completely dry.
• Check your user manual to see if there are specific installation or safety instructions for your part or appliance.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause injury.
• Wear safety glasses when working with chemicals, dust or cleaning large debris to prevent injury.
• If the appliance has recently been used, give it plenty of time for any heating parts to cool down before working on it.

Replacement steps

Removal

1. Locate the two lower bracket screws on the top panel and use the phillips screwdriver to remove them.
2. Pull the top panel back about an inch to disengage it from the washer, and then lift it off completely.
3. Find the steam generator and slide it towards the rear of the washer.
4. Use the phillips screwdriver to remove the four screws securing the mounting bar of the steam generator.
5. Push back the mounting bar and move the steam generator out of the way.
6. Locate the spring safety clip and use the flat blade screwdriver to pry it out.
7. Place the rope under the hook of the suspension spring.
8. With both hands, lift the spring up and out of the cabinet mounting hole.
9. Slowly lower the spring down and remove it from the outer tub mounting hole.
10. Repeat the steps to remove the other spring, if necessary.

Installation

1. Take the new suspension spring and hook one end through the mounting hole in the outer tub. Make sure that the upper hook is facing the cabinet.
2. Place the rope on the spring and lift the tub up slightly.
3. Hook the spring under the cabinet through the mounting hole.
4. Pull out the rope and attach the spring securely in place.
5. Lock the spring safety clip back into position.
6. Repeat these steps to install the opposite spring, if necessary.
7. Slide the steam generator mounting tabs into the corresponding cutouts in the cabinet.
8. Install the mounting bar so that the steam generator tab locks onto the mounting bar.
9. Align the four mounting holes and secure the bar with the screws.
10. Push the steam generator forward to lock it in place and then secure it with the two phillips screws.
11. Place the top panel back onto the washer and slide it forward until it locks into place.
12. Secure the top panel with the two phillips screws.
13. Turn on the water supply to the washer. Plug the washer back into the electrical outlet.
14. Test the washer to check for any problems.
