How to test the warming element on a Samsung range

If your Samsung electric range surface warming element isn’t heating, the problem may be with the element itself. Before you call for a repair technician, you can quickly test the part yourself to determine if it’s the source of the issue. By following the steps outlined in this guide, you’ll have the knowledge to troubleshoot the problem and get your appliance back up and running.

If you find out that you need any replacement parts for your appliance, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

The troubleshooting information in this article is based on general service manuals and may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

Tools and materials

• Phillips head screwdriver
• Multimeter

The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before attempting any maintenance or replacement work. This keeps you safe by preventing any risk of injury from electric shock.
• Wear insulated work gloves to protect your hands from sharp metal parts, pinching hazards and debris.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access the interior parts.
• Clear your workspace of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with bare wet hands. Make sure the work area is completely dry.
• Check your user manual to see if there are specific installation or safety instructions for your part or appliance.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause injury.
• Wear safety glasses when working with chemicals, dust or cleaning large debris to prevent injury.
• If the appliance has recently been used, give it plenty of time for any heating parts to cool down before working on it.
• Take pictures or make a note of wiring terminals or other connections before disconnecting to prevent any problems with reassembly.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.

Testing steps

Step 1: Access the warming element:

1. Remove the main top of the range by unscrewing the Phillips head screws around the top edge.
2. Open the oven door and remove any additional screws at the top of the oven opening to flip the top over and gain access to the warming element.

Step 2: Test the thermostats:

1. Set your multimeter to continuity mode.
2. Use the probes to test the thermostat with the yellow and violet wires. It should have continuity at room temperature.
3. The other thermostat, with the black and gray wires, should not have continuity at room temperature.

Step 3: Test the voltage:

LIVE VOLTAGE WARNING: For this test, the range needs to be plugged in and powered on. Please be very careful to protect yourself from electric shock, which has the potential to cause serious injuries. Don’t ever test live voltage if you’re uncomfortable using a multimeter.

1. Set your multimeter to VAC (Volts AC).
2. Use the probes to test the red and yellow terminals for the warming element.
3. Turn the control to the warming element on and test from one terminal to the other. You should get 120 VAC on the meter.
4. If you got 120 VAC and the element isn’t coming on, then the warming element is likely faulty and needs to be replaced.

Step 4: Reassemble the range:

1. Flip the cooktop back over and set it in place.
2. Reinstall the screws to secure the cooktop to the range.

Additional information
