Samsung refrigerator icemaker fill tube DA97-00209Z guide

Is your ice maker leaving you high and dry, especially when you’re in desperate need of ice? Over time, the plastic fill tube in your refrigerator might crack or freeze, putting an end to your ice-making dreams. But don’t worry, we’ve got you covered with a step-by-step guide and a handy how-to video that will help you replace this crucial part and get your ice maker back to full functionality.

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

Having an automatic ice maker in your refrigerator provides the convenience of ice-ready anytime you need it. But over time, the plastic fill tube that delivers water to the ice maker can crack or freeze up. When this happens, ice production grinds to a halt. Replacing this part can help restore your ice maker’s operation.

Watch the full repair here!

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

What you’ll need

Gather the following tools and parts prior to starting:

• Samsung Ice Maker Fill Tube Part (#DA97-00209Z) – Confirm this part number matches your specific Samsung refrigerator model.
• Phillips and Flathead Screwdrivers – For detaching screw covers and connections.
• 10mm Socket Wrench – To remove freezer door mounting bolts.

Make sure to turn off the refrigerator’s water supply valve before beginning. This will prevent leaks during the repair.

Safety precautions

Safety should always be a priority when working on any appliance. Here are a few practical tips to help you stay safe:

• Turn off the power to the appliance by unplugging it or switching off the circuit breaker before starting any maintenance or repairs. This protects you from the risk of electric shock.
• Wear insulated gloves to shield your hands from sharp edges, pinching hazards, or debris.
• Work at a steady pace and take your time to avoid accidents or injuries.
• Make sure your workspace is well-lit so you can clearly see and access the parts you’re working on.
• Keep the area clear of clutter, and ensure children and pets stay out of the workspace.
• Never handle internal parts with wet hands. Check that both your hands and the work area are completely dry.
• Refer to your appliance’s user manual for any specific instructions or safety guidelines related to the part or repair.
• Handle parts gently to avoid damage to the appliance or potential injuries from applying too much force.
• Use safety glasses when dealing with chemicals, dust, or large debris to protect your eyes from harm.
• If the appliance was recently used, give it enough time to cool down before working on any heated components.
• Take photos or notes of wiring connections and terminals before disconnecting anything to make reassembly easier.
• Avoid touching exposed wires or terminals. If you must handle wires, use non-conductive tools or wear insulated gloves to minimize the risk of electrical shock.

Remove freezer interior components

1. Pull out the wire baskets fully and lift up to remove them.
2. Slide the top freezer drawer out completely until the locking tab is free. Lift the drawer up and off the rails.
3. Carefully detach the freezer door by tilting it forward to release the bottom hinges. Lift the door up and off.

Clearing out the freezer interior allows room to detach and replace the fill tube.

Detach the ice maker assembly

1. Use a Phillips screwdriver to remove the screws securing the ice maker assembly.
2. Pull the assembly out enough to access the plug connector.
3. Press the tab to release the plug and disconnect. This avoids wire damage during handling.

The disconnected ice maker provides access to the fill tube connections.

Remove the old fill tube

1. Use a flathead screwdriver to pry off the protective cap from the tube’s water line fitting.
2. Press the release collar and pull firmly to detach the water line from the old fill tube.
3. Remove the retaining clip screw with a Phillips screwdriver.
4. Take out the two cover screws and slide the cover down.
5. Pull the old fill tube out of the refrigerator compartment opening. Discard it.

The refrigerator is now prepped and ready for the new replacement tube.

Install the new fill tube

1. Insert the new fill tube into the opening in the back of the fridge compartment.
2. Position the cover over the end of the tube and replace the two Phillips screws to secure it.
3. Attach the retaining clip over the water line and tighten its screw.
4. Push the water line back into the fill tube fitting until it clicks and locks.
5. Press the protective cap over the fitting to complete the connections.

With the new fill tube in place, reassemble the remaining components.

Reinstall the ice maker

1. Ensure the fill tube aligns properly in the ice maker before inserting it fully.
2. Plug the electric connection back into the ice maker. Listen for the click.
3. Replace the mounting screws to secure the ice maker in its position.

Replace the freezer components

1. Insert the rails into their slots simultaneously, then align the door holes with the rail pegs.
2. Replace the wire baskets, sliding them onto their frames properly.
3. Set the top drawer onto the rails and push back until the locking tab engages.
4. Turn the water supply back on and verify no leaks exist.

With these final steps complete, you should now have a fully functioning ice maker.

More information

We hope this article helped you replace the ice maker fill tube DA97-00209Z  on your Samsung refrigerator. If you’d like to watch the full repair, you can do so here.
