How to install GE dishwasher door latch WD13X10031

Is your GE dishwasher suddenly refusing to shut properly or perhaps leaking onto your kitchen floor? A faulty door latch could be the pesky culprit behind these problems, but don’t worry—we’ve got you covered. Dive into our step-by-step guide and watch our how-to video below to easily replace your dishwasher’s door latch and restore its full functionality.

When your GE dishwasher starts acting up, one of the first things to check is the door latch. A malfunctioning dishwasher door latch can be more than just a nuisance — it can also prevent your dishwasher from operating correctly.

If you need to order a new door latch WD13X10031, you can get one here. Make sure it’s compatible with your dishwasher model.

Let’s walk through the repair process together so you can get your GE dishwasher up and running smoothly again.

WATCH: How to install GE dishwasher door latch WD13X10031

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

Importance of the door latch

The door latch on your dishwasher keeps the door closed during the washing cycle.

If the door latch is faulty, your dishwasher door may not stay shut, the machine might not start, or you may experience water leaks. And no one wants water running out onto their kitchen floor!

What you need

• Philips screwdriver: For unscrewing and securing the door panel.
• 1/4-inch socket wrench: For handling smaller components.
• Small flat-blade screwdriver: For prying connectors.
• Replacement part: WD13X10031 (Take your model number to AppliancePartsPros.com to locate the correct part for your model)

READ MORE: Why It’s Best to Choose OEM Over Aftermarket Parts for Appliance Repairs

Keep safety first

Before you start any repair work on your appliance, safety should be your top priority.

• Always make sure your appliance is unplugged from the power source or the circuit breaker is turned off to prevent any electrical mishaps during the repair process.
• Turn off the water to the unit to prevent water leaks while you’re working on your dishwasher.

Replacement steps

Carefully follow these steps to install your new GE dishwasher door latch.

Step 1 – Access the door latch

Starting with the dishwasher’s door, locate the screws at the bottom corners.

Using your socket wrench, remove the screws.

READ MORE: My part is no longer available! What do I do now?

Step 2 – Remove the inner door panel

Remove the inner door panel screws completely. This allows the inner and outer doors to be separated, which makes your job easier. While removing the outer door panel, the touchpad connector will need to be disconnected.

Step 3 – Disconnect the old latch

The old latch should now be visible.

With the door open slightly, take note of how the latch is positioned, then carefully unscrew and remove the latch.

READ MORE: 8 DIY Safety Tips

Step 4 – Detach the wires

Take note of how the wires are connected to the old latch so you can correctly install the new latch. Once you’ve made a note or taken a photo of the wire arrangement, detach them.

Step 5 – Install the new latch

Grab your new WD13X10031 latch.

Connect the wires following the arrangement you noted earlier. Position the new latch where the old one was and use the Philip screws to secure it. Make sure it’s snug but not overtightened.

READ MORE: 4 Simple Ways to Reduce Kitchen Waste

Step 6 – Reassemble the door

Now you can put everything back together.

Carefully align the inner and outer doors and secure them using the screws you removed earlier. Make sure everything lines up correctly as you’re doing this.

Test the dishwasher

After reassembling your dishwasher, make sure all screws are tight and the door closes smoothly.

Plug in your dishwasher or turn the circuit breaker back on. Then run a test cycle to make sure everything is working as it should.

READ MORE: Best Loading Techniques For Your Dishwasher

Dishwasher maintenance tips

To prolong the life of your latch and dishwasher:

• Keep the latch area clean from debris and detergent build-up with a mild detergent and soft cloth. Avoid abrasive cleaners.
• Avoid slamming the dishwasher door.
• Regularly check for and tighten any loose screws or bolts.
• Keep the latch mechanism lubricated with a silicone-based lubricant.
• Clean the dishwasher’s filter(s) at least once every six months.
• Regularly wipe down the rubber seals and the door with a damp cloth to prevent soil and grime from building up.
• Regularly inspect and wipe down the spray arm. Remove the spray arm to clear any blockages with a toothpick every six months.

READ MORE: Surprising Things That Can & Can’t Go in the Dishwasher

More information

Thanks for reading! We hope this guide helped you replace the door latch in your GE dishwasher.
