How to replace a Whirlpool washer vacuum break inlet hose

Feeling overwhelmed by leaks or restricted water flow from your Whirlpool washer? You might be dealing with a worn-out vacuum break inlet hose, but don’t worry—replacing it is easier than you think! Our step-by-step guide and how-to video below will walk you through this simple DIY repair, ensuring your washer runs smoothly once again.

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

On a Whirlpool washer, the vacuum break inlet hose is responsible for supplying water to the tub while preventing backflow and maintaining water pressure, allowing your washer to fill with water for the wash and rinse cycles.

Common signs that indicate the need for replacement include leaks during the fill cycle, restricted water flow into the tub, or signs of physical damage such as cracks.

Fortunately, with a few basic tools and some patience, you can tackle this repair yourself and get your washer back in working order. So, let’s get started!

You can find a replacement vacuum break inlet hose here. If you need other replacement parts for your Whirlpool washer, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.

Watch here: How To: Whirlpool/KitchenAid/Maytag Vacuum Break Inlet Hose WP3357328

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

Tools and materials

• Replacement part (make sure it’s compatible with your model before installing)
• Flat head screwdriver
• Phillips screwdriver
• Pliers

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before attempting any maintenance or replacement work. This keeps you safe by preventing any risk of injury from electric shock.
• Turn off the water supply at the outlet before beginning repairs to any appliance parts that hold water. Have towels ready for any residual water in the system when removing parts.
• Wear insulated work gloves to protect your hands from sharp metal parts, pinching hazards and debris.
• Don’t test wiring with a multimeter for live voltage if you’re unfamiliar with how to prevent short circuiting when testing.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access the interior parts.
• Clear your workspace of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with bare wet hands. Make sure the work area is completely dry.
• Check your user manual to see if there are specific installation or safety instructions for your part or appliance.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause injury.
• Wear safety glasses when working with chemicals, dust or cleaning large debris to prevent injury.
• If the appliance has recently been used, give it plenty of time for any heating parts to cool down before working on it.
• Take pictures or make a note of wiring connections before disconnecting to prevent any problems with reassembly.

Replacement steps

Step 1: Disassembly

1. Remove the two screws holding the control panel in place at the front and rear.
2. Lift off any trim covers or use a putty knife to release spring clips.
3. Slide the control panel forward about 1/2 an inch and lift it back over the back of the machine.
4. Disconnect the lid switch and use a flathead screwdriver to pry out the two retaining spring clips that hold the body to the frame.
5. Lift up on the lid, grab the body near the front, put your foot against the body of the machine, tilt the body back to about a 45-degree angle, and carefully lift it off the washer.
6. With the cabinet off, locate the vacuum break inlet hose. It is typically connected to the water valve and the vacuum break. To access the hose, remove the clamp that holds it to the water valve. Pull the hose off the valve. Repeat the same process for the upper end of the hose attached to the vacuum break.

Step 2: Reassembly

1. Remove the clamps from the old hose and put them on the new hose.
2. Reroute the new hose through the plastic retainer. Push the lower end of the hose onto the water valve.
3. Use pliers to slide the clamp up and secure the hose to the valve.
4. Connect the upper end of the hose to the vacuum break.
5. Push the hose onto the vacuum break and use pliers to slide the clamp into place.
6. Hold the body at a 45-degree angle and swing it back onto the washing machine.
7. When sliding the body back onto the frame, make sure the lower lip goes underneath the frame, then lower it down onto the four locking tabs.
8. Hook the retaining spring clips onto the back panel and use a flathead screwdriver to push them down into place.
9. Reconnect the lid switch that was disconnected during disassembly.
10. Rotate the control panel forward over the front of the machine, ensuring the locking tabs lock in place.
11. Pull it back about half an inch and replace the screws.
12. Plug the washer back in and turn the water back on.
13. Test the washer to check for any problems.

Additional information
