Frigidaire 154754302 Nozzle (Spray Arm) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 154754302 replaces AP6261460.

Description

This dishwasher nozzle channels wash water into the spray arm to deliver full coverage. If the nozzle is cracked, missing, or clogged with debris, spray pressure drops and cleaning suffers—replacing it restores proper wash performance.

• Directs wash water from the feed tube to the spray arm
• Helps maintain correct spray pressure and arm rotation
• Replace when damaged, worn, or blocked by mineral deposits/food debris
• Typical symptoms: poor cleaning, spray arm not spinning, weak or uneven spray

Includes: 1 nozzle Install notes:

• Disconnect power and water supply before servicing
• Pull out rack and remove the spray arm or supply tube to access the nozzle (location varies by model)
• Release/twist out the old nozzle and seat the new one securely
• Run a short test cycle to confirm no leaks and free spray arm movement
