Speedqueen D517557 Dryer Timer (3-Cycle, 120V/60Hz) OEM Part

Product Details

Genuine Speedqueen part.

Cross Reference Information

Part Number D517557 replaces AP6990315.

Description

This mechanical timer controls cycle selection and run time on 3-cycle 120V/60Hz dryers. Replacing a worn timer restores proper start, advance, and automatic shutoff so loads finish on time without constant monitoring.

• Drives the cam and switches to power the motor/heat, advancing the selected cycle
• Coordinates cycle timing and end-of-cycle shutoff
• Common failure symptoms: timer doesn't advance or stalls mid-cycle
• Dryer runs continuously or stops too soon
• Won't start on certain settings, or only one cycle works; timer may buzz/click without moving

What's included: Timer assembly only Install notes:

• Disconnect power before service; for gas dryers, shut off gas supply if moving the unit
• Photograph and label wiring; transfer wires one at a time to matching terminals
• Mount securely; ensure the timer shaft turns freely before reassembly
• Inspect terminals/harness for heat damage and replace any compromised connectors
