Whirlpool W11549931 Electronic Control Board (Console Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11549931 replaces AP7034325.

Description

This electronic control board replaces the main console controller to restore electronic operation and user input for your appliance. It manages cycle selection and overall electronic coordination so the appliance responds correctly to commands. What it does:

• Receives and processes user inputs from the console or touchpad
• Sends commands to heating, motor, and timing circuits to run selected cycles
• Manages timing and sequence logic for normal operation
• Can resolve issues like unresponsive controls, error codes tied to the console, or intermittent operation when the control board is faulty

What's included: One electronic control board Install notes:

• Disconnect power to the appliance before beginning any work to avoid shock or damage
• Handle the board carefully and avoid touching circuit components; use ESD precautions when possible
• Installation typically requires removing the console or control panel and unplugging wire harnesses; keep harness locations noted for reassembly
