Whirlpool W11690997 Electronic Control Board (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11690997 replaces AP7217354, W11100268, W11333314.

Description

This electronic control board is the appliance's main board that governs cycle selection, timing, and user interface signals so the appliance operates as programmed. Replacing a faulty board restores consistent control and display response. What it does

• Receives input from the user console and sensors, then directs motors, valves, and heaters
• Can cause no power to controls, unresponsive buttons, or failure to start when failing
• May produce error codes or interrupted cycles if contacts or circuitry are damaged
• Enables normal cycle sequencing and timing when functioning correctly

What's included One electronic control board (single unit) Install notes

• Disconnect power at the breaker or unplug the appliance before starting
• Handle the board by its edges and avoid touching components to prevent ESD damage
• Follow OEM disassembly steps
