Whirlpool W11309270 Control Box (Electronic Control Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11309270 replaces AP6832810, W11188489.

Description

This control box is the appliance's electronic command center, replacing a failed control assembly to restore cycle selection and timed operations. It provides reliable switching and control of the unit's functions when working properly. What it does:

• Receives user inputs and signals other components to start, stop, or change cycles
• Regulates timing, sequencing, and control of motors, valves, or heaters depending on model
• Commonly replaces a control that causes no response, erratic cycles, or unresponsive controls
• Helps resolve problems like no lights, no cycle start, or intermittent operation linked to control failure

What's included:

• One control box (electronic control assembly)

Install notes:

• Disconnect power before servicing; electric shock hazard
• Handle the board by edges and avoid static discharge; use anti-static precautions
• Verify connectors align and seat fully; do not force connectors onto pins
