Whirlpool W11496885 Control Box (Electronic Control Module) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11496885 replaces AP7033553, W11221332, W11239667, W11396168.

Description

This electronic control module manages the appliance's timed functions and user commands so cycles run correctly and features respond as expected. It replaces a failed control assembly to restore control and cycle operation. What it does:

• Receives input from the user interface and sends signals to motors, valves, heaters and other components
• Controls cycle timing, sequencing and feature activation
• Can stop proper operation when damaged, causing unresponsive controls or interrupted cycles
• Common symptom linkage: appliance won't start, display is blank or unresponsive, cycles fail to advance, or intermittent operation

What's included:

• One control box (electronic control module)

Install notes:

• Disconnect power before service to avoid electrical shock
• Handle the board carefully and avoid touching exposed circuitry or connectors
• Transfer any mounting brackets or harnesses exactly as removed; confirm connector seating before reapplying power
