Whirlpool W11546126 Control Box (Electrical Control Module) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11546126 replaces AP7175860.

Description

This control box is the appliance's main electrical control module that manages timed operations and electronic functions, helping restore proper cycle control and responsiveness to user commands. What it does:

• Receives and routes power to electronic components and relays for timed cycles
• Controls start/stop, cycle selection and other electronic commands
• Can cause failure to start, unresponsive controls, or erratic cycle behavior when faulty
• Replaces a failed or damaged control module to restore normal electronic operation

What's included: One control box electrical module (assembly) Install notes:

• Disconnect power to the appliance before servicing to avoid shock or injury
• Handle the control module and circuit board by edges; avoid touching contacts
• Reuse mounting hardware only if intact; replace damaged connectors or wiring
