Whirlpool W11568810 Control Box (Electrical Control Module) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11568810 replaces AP7186733.

Description

This control box is the appliance's electronic control module that manages cycles, timing and user interface functions. Replacing a failed control box restores proper electronic control and helps return the appliance to normal operation. What it does

• Receives button/knob inputs and runs selected cycles according to programmed logic
• Controls power to motors, heaters and valves via internal relays and circuitry
• Can resolve symptoms like no response to controls, intermittent operation, or failure to start
• Helps clear erratic behavior caused by a damaged or shorted control assembly

What's included One control box assembly. Install notes

• Disconnect power to the appliance before beginning any service
• Handle the control board and connectors by the edges; avoid touching components
• Transfer any user interface, bracketry or harnesses exactly as removed
