Whirlpool WPW10392485 Wire Harness (Bldc Motor Harness) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10392485 replaces AP6020807, W10392485.

Description

This wire harness connects the BLDC (brushless DC) motor assembly to the appliance control, restoring reliable electrical connections and component communication. It replaces a worn or damaged motor harness so the motor and controls can operate properly. What it does:

• Provides the electrical pathway between the BLDC motor and the control board for power and signal lines
• Restores intermittent or lost motor power caused by frayed, broken, or corroded wires
• Can stop motor-related errors or unexpected shutdowns when the original harness is damaged
• Ensures proper connector fit and routing to prevent chafing and short circuits

What's included: One wire harness as shown. Install notes:

• Disconnect power before starting and verify power is off at the breaker or plug
• Handle connectors by the housings; avoid pulling on wires to prevent damage
• Route harness following original clips and channels to prevent pinching or rubbing
