Whirlpool WPW10392488 Wire Harness (Bldc Motor) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10392488 replaces AP6020809, 4446199, PS11754129, W10392488.

Description

This wire harness connects and routes power and signals for the appliance's BLDC motor, restoring reliable electrical connections so the motor can run smoothly. Ideal when the original harness is damaged, burnt, or has broken terminals. What it does

• Carries power and control signals between the BLDC motor and the control board.
• Replaces damaged, frayed, or corroded wiring that can cause motor errors or intermittent operation.
• Helps stop poor motor performance, unusual noises, or failures caused by loose or broken connectors.
• Maintains correct connector pinout and secure mating to prevent shorts and voltage drops.

What's included

• One wire harness as shown.

Install notes

• Disconnect power before servicing the appliance to avoid electrical shock.
• Verify connectors match the motor and control board before final installation; align keyed connectors and seat fully.
• Handle terminals gently to avoid bending pins; secure harness away from hot or moving parts.
