Whirlpool W10481152 Wire Harness (Main Appliance Connector) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10481152 replaces AP5620239.

Description

This wire harness provides the factory-style wiring connections between the appliance control and its components to restore reliable electrical paths and communication. It replaces a damaged or burnt harness to help return normal operation and safety. What it does:

• Provides factory routing and plug-to-plug connections between the control and components.
• Restores power and signal continuity when broken, chafed, or melted wires cause failures.
• Common symptom: appliance won't power on or specific functions stop responding.
• Common symptom: intermittent operation, error codes, or visible wiring damage.

What's included:

• One complete wire harness as shown.

Install notes:

• Disconnect power (unplug or switch off breaker) before starting work.
• Verify connector orientation and routing match the original harness; secure with existing clips and ties.
• Avoid crimping or stressing terminals; replace any damaged retainers or strain reliefs.
