Whirlpool W10583026 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10583026 replaces AP5807520.

Description

This wire harness assembly routes electrical signals and power between the appliance control and its components, restoring reliable connections for proper operation. Use when wiring is damaged, burned, or causing intermittent or no power to parts. What it does

• Provides factory-style wiring connections between the control board and components.
• Replaces frayed, melted, or corroded wires that can cause shorts or intermittent operation.
• Helps stop symptoms such as no power to specific components, erratic behavior, or burning/overheating at wire junctions.
• Ensures correct wire routing and connector fit for safe appliance function.

What's included One complete wire harness assembly as shown. Install notes

• Disconnect power (unplug or shut off breaker) before starting any repair.
• Inspect connectors and mating components; replace any damaged terminals or clips.
• Note or photograph original routing and connector positions to ensure correct reassembly.
• Check related components and fuses for underlying faults.
