Whirlpool W10680048 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10680048 replaces AP5987667.

Description

This genuine wire harness routes power and control signals between the appliance's control and components, restoring reliable electrical connections for normal operation. Ideal when controls, lights, or motors fail to respond. What it does

• Connects control board, switches, and powered components so the appliance can operate
• Carries power and low-voltage signals to enable control functions
• Common symptom fix: appliance won't power on or controls/buttons are unresponsive
• Common symptom fix: intermittent operation, blown fuses, or erratic component behavior

What's included One wire harness. Install notes

• Disconnect the appliance from power (and water if applicable) before starting.
• Handle connectors carefully; match connector shapes and wire routing during removal and installation.
• Secure harness with existing clips or fasteners to avoid contact with hot or moving parts.
