Whirlpool W11090772 Wire Harness (Electrical Control Harness) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11090772 replaces AP6285424.

Description

This wire harness routes power and signals between the appliance control and internal components so the unit can operate reliably. It replaces a damaged or worn harness to restore secure electrical connections and proper function. What it does

• Carries power and control signals between the control board and internal parts.
• Helps stop intermittent operation caused by loose, frayed, or broken wires.
• Can prevent electrical arcing or poor connections that trigger errors or shutdowns.
• Restores factory wiring routing and connector fit for reliable component operation.

What's included One wire harness. Install notes

• Disconnect all power (unplug or shut off breaker) before starting any repair.
• Handle connectors and wires gently; avoid pulling on individual wires.
• Match connector shapes and wire routing to the original harness; secure with existing clips or ties.
• If you see melted connectors, exposed conductors, or other damage, replace the harness before restoring power.
