Whirlpool W11164375 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11164375 replaces AP6887310.

Description

This wire harness routes power and signals between components so your appliance's controls and motors communicate reliably. It replaces a worn or damaged harness to restore electrical connectivity and help resolve intermittent operation or no-power symptoms. What it does:

• Connects control board, switches, sensors, and motors using molded connectors and color-coded leads
• Restores continuity for circuits that fail due to frayed, burnt, or broken wiring
• Helps eliminate intermittent starts, no-power at components, or unexpected shutdowns caused by damaged harnesses
• Matches OEM routing and connector types for a direct fit replacement

What's included:

• One complete wire harness as shown

Install notes:

• Disconnect power (unplug or turn off breaker) before inspecting or replacing wiring
• Replace any damaged clips or fasteners to secure harness away from moving parts or hot surfaces
• If you see burned connectors or melted insulation, inspect the associated components and fuses before installing the new harness
