Whirlpool W11216796 Wire Harness (Complete Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11216796 replaces AP6871986.

Description

This wire harness routes power and signals between appliance components to restore reliable electrical connections and proper operation. It replaces damaged or corroded wiring to help eliminate intermittent faults and loss of function. What it does:

• Provides the factory-style wiring paths and connectors for the listed appliance circuits
• Restores power or signal continuity when original wires or connectors are frayed, burned, or broken
• Helps stop intermittent operation, shorts, or components that won't receive power
• Matches OEM connector ends and routing for a like-for-like replacement

What's included:

• One complete wire harness assembly as shown

Install notes:

• Disconnect all power (unplug or switch off breaker) before servicing to avoid shock or injury
• Compare new harness to the old unit before installation
• Handle connector terminals gently; avoid bending pins or pulling on individual wires
• Secure harness with existing clips or ties and verify connectors are fully seated before restoring power
