Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number W11310028 replaces AP6832814, W11109740.
Description
This wire harness assembly routes power and signals between the appliance control and its components, restoring electrical connections for reliable operation. Replace a damaged harness to fix intermittent power, control errors, or complete circuit failures. What it does:
- Provides bundled wiring to connect controls, sensors, and motors safely
- Restores continuity when chafed, burned, or broken wires cause faults
- Helps resolve symptoms like loss of function, intermittent operation, or error codes linked to wiring
- Keeps wire routing organized and insulated to prevent shorts
What's included: One wire harness assembly Install notes:
- Disconnect power (unplug or shut off breaker) before inspecting or replacing the harness
- Follow the appliance wiring diagram and attach matching connectors; do not force or re-pin connectors
- Avoid sharp bends and secure the harness with existing clips to prevent chafing
- If screws or terminal connections are corroded or damaged, replace them and verify all connections are tight before restoring power
