Whirlpool W11523109 Wire Harness (Electrical) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11523109 replaces AP7205921.

Description

This wire harness routes electrical power and signals between components to restore reliable circuit connections in your appliance. It replaces damaged or corroded wiring to help re-establish proper operation and reduce intermittent faults. What it does:

• Carries power and control signals between electrical components
• Replaces frayed, burnt, or broken wiring that can cause intermittent operation
• Restores secure plug-in connections to prevent shorts and open circuits
• Helps resolve symptoms such as lack of power to a component, intermittent cycles, or visible wiring damage

What's included: One wire harness as shown Install notes:

• Disconnect power (unplug or shut off circuit breaker) before servicing
• Document wire routing and connector locations or take photos to ensure correct reinstallation
• Route harness away from heat, sharp edges and moving parts; secure with existing clips or ties
• If connectors are damaged, replace them or the harness assembly; do not splice unless repair meets OEM safety standards
