Whirlpool W11697178 Wire Harness (Multi-Connector Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11697178 replaces AP7219207, W11515202, W11595231.

Description

This wire harness is the factory-style electrical assembly that links controls to components, restoring reliable power and signal routing so your appliance operates properly. It replaces a damaged or worn wiring assembly. What it does

• Routes power and control signals between the main control and appliance components
• Restores intermittent or non-functioning circuits caused by frayed, pinched, or broken wires
• Helps eliminate electrical shorts from damaged insulation or loose connections
• Useful when diagnostics find open circuits or faulty connector plugs

What's included

• One wire harness assembly as shown

Install notes

• Disconnect power to the appliance before starting any repair
• Compare harness connector shapes and pin counts to the original before installation
• Secure harness away from sharp edges, heat sources and moving parts to prevent damage
