Whirlpool W11495561 Magnetron (Microwave Heating Tube) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11495561 replaces AP7217407.

Description

• Converts electrical energy into microwave radiation that heats food in the oven cavity.
• Common symptom: oven runs but does not heat or heats very poorly.
• Other symptoms: unusual buzzing, arcing or sparking inside the cavity, or a burning/electrical smell.
• Should be checked alongside the high-voltage diode and capacitor when diagnosing no-heat conditions.

• One magnetron.

• Disconnect power and discharge the high-voltage capacitor before servicing; high-voltage components can retain a dangerous charge.
• Only install if you are experienced with microwave HV systems.
• Avoid touching the antenna or ceramic insulator; handle by the mounting flange and follow OEM torque and grounding instructions.
• Inspect and replace any damaged mounting hardware, gaskets, or nearby components to ensure proper fit and safe operation.
