Bosch 00411000 Bushing, Snap (1.00 In Id, 1.468 In Od) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others. See all items in Range / Cooktop / Oven Bumper, Bushing, Grommet.

Cross Reference Information

Part Number 00411000 replaces AP2828628, 1047615, 14-31-270-02, 411000, AH3456490, EA3456490, PS3456490.

Description

This snap bushing cushions and centers a rotating shaft or spacer, reducing wear and vibration for smooth appliance operation. Fits applications that require a 1.00 inch inside diameter and 1.468 inch outside diameter bushing. What it does:

• Provides a low-friction bearing surface to protect shafts and surrounding components from metal-on-metal wear
• Centers and stabilizes rotating parts to reduce vibration and noise
• Helps maintain proper clearance between moving parts for longer component life
• Used where a durable, press-fit snap bushing is needed for quick assembly

What's included:

• One snap bushing

Install notes:

• Press into a clean, burr-free hole until the bushing snaps fully into place; do not force at an angle
• Verify correct orientation so the retaining lip seats against the mounting panel
• Replace any damaged or excessively worn bushings to prevent further component damage
• Disconnect power and follow appliance safety procedures before accessing internal components
