Bosch 00617774 Cable Harness (Control Wiring), 1 Each OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 00617774 replaces AP4483228, 1560490, 617774, AH3478483, EA3478483, PS3478483.

Description

This cable harness routes power and control signals between the dishwasher control board and components, restoring reliable electrical connections for proper operation. Designed to replace damaged or worn wiring where connectors or insulation are compromised. What it does:

• Transfers power and control signals between the main control/module and subsystems (pumps, valves, sensors, motor)
• Replaces frayed, burned, or broken wires and damaged connector ends that cause intermittent operation or component failures
• Restores proper connector fit and wiring routing to prevent shorts and miscommunication
• Helps resolve symptoms like no power to components, intermittent function, or visible wiring damage

What's included: One replacement cable harness Install notes:

• Disconnect power to the appliance before starting work to avoid shock or damage
• Keep track of connector positions; take photos before removing the old harness for accurate reinstallation
• Route the new harness along the same path and secure any clips or ties to prevent pinching or contact with moving parts
• If you encounter corrosion or damaged connectors on mating parts, inspect and replace those components as needed
