Bosch 12009543 Control Module (Programme) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 12009543 replaces AP5984999, 4581398, PS11725049.

Description

Electronic control module that manages program selection, timing and the appliance's user controls. Replacing this module can restore proper cycle sequencing and control-panel responsiveness when the original control is faulty. What it does:

• Governs program selection, cycle timing and sequence control for the appliance's main functions.
• Restores responsiveness when buttons or touch controls do not register or the panel is unresponsive.
• Can address symptoms such as blank or flashing display/LEDs related to control failures.

What's included: One control module Install notes:

• Disconnect all power to the appliance before starting work to avoid shock; verify power is off at the breaker.
• Handle the module carefully and avoid touching circuit contacts; use a grounded wrist strap if available to reduce ESD risk.
• Ensure all wiring harness connectors are fully seated and routed correctly; recheck door latch and fuses before assuming module failure.
