Bosch 10023094 Display Module (Control Panel Display Board) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 10023094 replaces AP7204857, 12007476, 00758975.

Description

This display module is the electronic board behind the control panel that provides the readout for settings, alerts, and status. Replacing a failed module restores a clear, dependable display so you can monitor and operate the appliance correctly. What it does:

• Drives the LED/LCD indicators and digital readout on the control panel
• Communicates with the main control to show selected options, progress, and fault codes
• Helps restore normal visibility of settings and status information
• Common symptoms of failure: blank or dim screen, missing segments/characters, scrambled or flickering readout, display frozen or not updating

What's included:

• Includes: 1 display module

Install notes:

• Disconnect power at the breaker before servicing to avoid electrical shock
• Use ESD protection and handle the board by the edges to prevent static damage
• Note connector orientation; move any original mounting hardware/trim as required and seat all harnesses fully
• After reassembly, restore power and run any model-specific diagnostic or self-test as directed by the service documentation
