Bosch 00488360 Electrode (Ignition/Spark) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others. See all items in Range / Cooktop / Oven Igniter.

Cross Reference Information

Part Number 00488360 replaces AP3195900, 00414562, 08-04-587, 08-04-727, 1052428, 35-00-932, 414562, 488360, AH3471598, EA3471598, PS3471598, PS8721869.

Description

Electrode that produces the ignition spark for gas ovens and ranges, restoring reliable burner lighting. Replace a damaged or worn electrode to stop repeated clicking, weak sparks, or burners that fail to light. What it does:

• Delivers the spark at the burner to ignite gas during startup.
• Common symptom fix: oven/range burners that won't light or that click continuously without producing a flame.
• Use when the electrode is cracked, corroded, or the ceramic insulator is damaged.
• Works as part of the appliance's ignition system alongside the spark module/igniter wiring.

What's included: One electrode. Install notes:

• Turn off power and gas supply before beginning any service.
• Avoid touching or chipping the ceramic insulator; handle the tip carefully.
• Reconnect wiring exactly as removed and secure the electrode in the original orientation.
