Bosch 00413194 Thermal Fuse (Temperature Cutoff) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others. See all items in Range / Cooktop / Oven Fuse Or Sensor.

Cross Reference Information

Part Number 00413194 replaces AP2830500, 1048255, 14-39-381, 413194, AH3458678, EA3458678, PS3458678, PS8709017.

Description

This thermal fuse is a one-time temperature cutoff that helps protect the appliance from overheating by interrupting power when temperatures exceed a safe threshold. It restores safe operation only after replacement. What it does:

• Cuts electrical current if internal temperatures climb above the designed limit to prevent component damage or fire risk.
• Commonly used to protect motors, heaters, or control circuits from overheating.
• Symptom linkage: may be the cause when the appliance or a specific function has no power or stops mid-cycle.
• Designed for single-use operation—once triggered, it must be replaced.

What's included:

• One thermal fuse

Install notes:

• Disconnect power at the breaker or unplug the appliance before servicing.
• Replace with the exact Bosch part number or other approved equivalent; do not jumper or bypass the fuse.
• Handle with care; verify correct location and orientation.
