Kevin K Willow Street , PA May 23, 2017 Appliance: Bosch Freestanding Dual Fuel Range HDS7062U/01 Electric oven in our bosch stove would not heat properly Diagnosed the system using schematic on back of oven. With power ON (BE VERY CAREFUL - VERY DANGEROUS). Relay board was working - was providing 220VAC to Main Bake Element and Convection Element - even during pre-heat. Temp would not to past 400 - and temp would drop when oven door was opened. With Power OFF - disconnected one of the power leads to the bake element to properly measure its resistance - approx.. 20-25 ohms DC resistance - Element OK. Replace lead to Bake Element. Disconnected one of the leads to the Convection Element - to properly measure it resistance - OPEN CIRCUIT - BINGO !!! Ordered a new Convection Element from AppliancePartsPros.com at 9:30 PM !!! The new element came 2 days later. Measured its resistance - approx. 40 ohms - LOOKING GOOD. Removed the old Convection Element, and installed the new one in about 10 minutes. Our Bosch sove's Oven is working as good as new !! Read More... 8 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 2+ hours Tools: Screwdrivers
Gary C Sulphur , LA December 03, 2018 Appliance: Model BOSCH DUAL GAS ELECTRIC Oven not getting up to temp in bake mode Replaced convection element and bake element. Both tested OK but all I can do is check resistance. Stove is 10 plus years old and an expensive appliance. Works fine now so apparently the elements can get weak without burning out completely. Parts were reasonably priced and arrived in a short time. Read More... 5 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers
Georg B San Mateo , CA August 21, 2019 Appliance: Bosch Dual-Fuel Range HDI7282U/03 Bosch oven was taking a long time to reach temperature and after reaching temp and opening the door it would go into pre heating mode again and not be able to reach temperature. Changed the convection fan heating element. Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Pliers, Screwdrivers
Zach A Raleigh , NC March 14, 2018 Appliance: Model HEI7282U/09 Bosch HEI7282u/09 not heating all the way The oven wouldn't reach temperature on bake - it broiled fine. I checked the resistance on the bake and convection elements & temp sensors. Bake element 29.2 ohms Temp sensor 1083 ohms Convection element infinite I put in a new convection element and it works like a champ. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
