Bosch 11030599 Ice Maker Assembly (Refrigerator) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 11030599 replaces AP6833405, 11034802.

Description

Restore dependable ice production with this replacement ice maker assembly. It automatically fills, freezes, and ejects cubes into the bin, resolving common ice maker failures so your refrigerator consistently makes ice again without using manual trays.

• Produces ice by controlling the fill, freeze, and ejection cycle
• Coordinates with the water inlet valve for proper fill levels
• Stops making ice when the bin is full to prevent overfilling
• Common symptoms: no ice production, cubes not ejecting, leaking/overfilling at the ice maker, or clicking/grinding from the unit

What's included: 1 icemaker assembly Install notes:

• Disconnect power and turn off the household water supply before servicing
• Remove the ice bin/cover, release mounting hardware, and unplug the wire connector; transfer brackets/screws as needed
• Ensure the fill tube is correctly aligned with the ice maker's fill cup
• After installation, restore power/water and discard the first batches of ice as the system clears
