Bosch 00646750 Insulating Plate (Waveguide Cover) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 00646750 replaces AP4483303, 1560981, 646750, AH3479976, EA3479976, PS3479976, PS8730546.

Description

This insulating plate serves as the microwave's waveguide cover. It shields the waveguide opening from steam and splatter while allowing energy to enter the cavity, helping prevent arcing and protecting internal components and cavity surfaces.

• Shields the waveguide/magnetron opening from grease and moisture
• Electrically insulates the feed area to reduce arcing
• Helps maintain proper microwave energy distribution into the cavity
• Common signs of failure: sparking from the side wall, burn marks on the cover, sizzling/burning odor during cooking, or a visibly cracked/charred plate

What's included: 1 insulating plate Installation notes:

• Disconnect power before servicing; never operate the microwave without this cover installed
• Remove the retaining screw or release tabs, note orientation, and seat the new plate flush over the waveguide opening
• If arcing occurred, clean any carbonized residue from the cavity surface before installing the replacement
