Bosch 12019087 Power Module (Main Control Board) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 12019087 replaces AP6241065, 00753014, 753014.

Description

Electronic power module for the dishwasher. This is the main control board that manages power and timing for wash, drain, and drying functions, helping restore normal operation when the original module has failed or is intermittent.

• Regulates incoming power and switches major loads (circulation pump, drain pump, heater, inlet valve)
• Coordinates cycle logic based on door and sensor inputs
• May help when the dishwasher won't power on or start a cycle
• May help when cycles stop mid-way, don't complete, or drying performance is poor

What's included: One power module assembly. Install notes:

• Disconnect electrical power at the circuit breaker before servicing
• Access is typically from behind the lower toe panel/base; remove panels as needed
• Photograph and label wiring; transfer any mounting hardware; seat connectors fully
• Use ESD protection and handle the board by its edges only
