Bosch 00414462 Spacer (Therm Dial) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 00414462 replaces AP2831893, 1100168, 14-19-904, 414462, AH3459945, EA3459945, PS3459945.

Description

This small spacer positions and secures the temperature/thermostat dial on the control panel, keeping the dial aligned for accurate user control and smooth rotation. It's a simple replace-and-forget part when the dial feels loose or off-center. What it does

• Centers the therm/temperature dial on the control shaft to ensure even contact and smooth rotation
• Prevents dial wobble, slippage, and misalignment that can make settings hard to read or select
• Helps maintain consistent user control for temperature adjustments
• Works behind the control panel as a passive mounting/spacing component

What's included One spacer Install notes

• Disconnect power to the appliance before accessing the control panel to avoid electrical shock
• Remove the control panel or trim per the appliance service instructions to reach the dial assembly
• Note the spacer orientation during removal so the replacement installs the same way
• Handle small parts carefully; keep screws and related components together for reassembly
