Bosch 11012631 Spray Arm OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 11012631 replaces AP5999933, 00668147, 4455893, 668147, PS11732432.

Description

This dishwasher spray arm distributes pressurized wash water through rotating jets to cover dishes evenly. Replacing a cracked or clogged arm restores proper spray pattern and helps improve cleaning performance across the racks.

• Channels water from the circulation pump through multiple nozzles for effective cleaning
• Rotates to deliver even coverage throughout the tub
• Wear, cracks, or mineral buildup can restrict flow or stop rotation
• Typical symptoms: poor cleaning results, spray arm not spinning, uneven spray patterns, or visible damage

What's included: 1 spray arm

• Disconnect power at the breaker and shut off water supply
• Remove the rack if needed; release the arm by pressing its tab or twisting the hub (design varies)
• Clear debris from the jets and check the mounting hub/seal before installation
• Install until fully seated and spinning freely; run a test cycle to operation
