Bosch 00611338 Door Balance Spring (Dishwasher) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 00611338 replaces AP4482992, 1559817, 611338, AH3477705, EA3477705, PS3477705.

Description

This spring counterbalances the dishwasher door so it opens smoothly and doesn't drop. Replacing a worn or broken hinge spring restores proper door tension and controlled movement to protect the hinges and front panel.

• Provides tension through the door hinge/cable system to balance the door weight
• Enables smooth, controlled opening and closing
• Symptoms of failure: door drops quickly, feels heavy, or won't hold a partially open position

What's included: 1 spring Install notes:

• Disconnect power and turn off water before servicing
• Support the door; use eye and hand protection—springs are under tension
• Note spring hook locations and routing before removal; transfer to the same positions
• After replacement, check door balance and operation; replace both springs if tension is uneven side-to-side
