Bosch 00414518 Switch Latch (Door Latch Switch) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others.

Cross Reference Information

Part Number 00414518 replaces AP2831949, 1048764, 14-19-016, 414518, AH3460001, EA3460001, PS3460001.

Description

This door latch switch is the user-interface microswitch that detects and secures the oven/microwave door, allowing the unit to start and run safely. Replaces a worn or failed latch switch to restore reliable door sensing and control. What it does

• Acts as the electrical switch that signals when the door is closed and ready for operation.
• Prevents operation if the door is not fully latched or the switch fails to indicate a closed door.
• Commonly replaced when the oven/microwave won't start, stops mid-cycle, or door-related safety errors appear.
• Small internal switch assembly mounts to the latch mechanism and provides the door-closed contact.

What's included

• One door latch switch assembly.

Install notes

• Disconnect power before servicing to avoid shock—this part interacts with mains circuitry.
• Remove outer door panel or control housing as required for access; keep track of fasteners and wiring orientation.
• Inspect connector terminals and wiring for damage; replace if corroded or frayed.
